October 26, 2021

Robotic massage helps regenerate muscles in mice

At a Glance

  • Researchers found that a type of massage therapy helped heal severely injured muscles in mice by clearing immune cells from the tissue.
  • The findings add to evidence that mechanical therapies can help improve tissue regeneration.
Mouse muscle Immunofluorescence images show that when an injured muscle is treated with mechanotherapy (top), its muscle fiber type composition changes compared to untreated muscles (bottom). The resulting treated muscle is more similar to that of healthy muscle, implying that treatment helps restore proper muscle function. Wyss Institute at Harvard University

Massage has long been used to treat sore muscles and relieve stress. Recent studies have shown that these “mechanotherapies” can also improve muscle healing. Applying mechanical forces to injured tissue can aid regeneration and improve muscle function. However, the process underlying these benefits isn’t well understood.

A team led by Dr. David Mooney of Harvard University set out to study how massage may speed muscle healing. Earlier work from the group showed that mechanotherapy doubled the rate of muscle regeneration and reduced tissue scarring in injured mice. Their new study was funded by several NIH institutes. Results were published in Science Translational Medicine on October 6, 2021.

The team developed a robotic device to precisely control the force applied to a mouse’s injured leg muscles. The device used a force sensor covered with soft silicone. An ultrasound above the muscle measured tissue strain from the repeated compressions. The team applied the mechanotherapy to the injured mice each day over 14 days. Three different force levels were tested.

They found that the treatment significantly reduced damaged muscle fibers and scar tissue compared to untreated mice. Contraction strength continued to improve throughout treatment until the treated muscle performed better than uninjured muscle. Improvements were similar across all force levels.

The researchers next explored why the robotic compression helped muscle repair. They theorized the treatment might affect the body’s inflammatory response after injury. They thus analyzed a broad range of proteins, called cytokines and chemokines, involved in inflammation. These play an important role in repairing injured tissue.

They found reduced levels of most inflammatory factors after the third day of mechanotherapy. Further analyses revealed substantial reductions in a set of cytokines involved in attracting and activating immune cells called neutrophils, which are key players in inflammation. The long-term presence of neutrophils is thought to impair muscle regeneration.

The team then tested the theory that mechanotherapy helped clear cytokines and neutrophils from injured tissue. Injecting fluorescent molecules into the tissue revealed greater spread after treatment, supporting this idea.

The results show that mechanotherapy substantially improves recovery of severely injured muscles in mice. This improvement is likely due to the rapid clearance of neutrophils and inflammatory factors, which impede healing.

“This research has revealed a previously unknown type of interplay between mechanobiology and immunology that may be critical for muscle tissue healing,” Mooney says. “It’s a testament to how crucial it is to consider both physical and biological elements when studying and working to improve human health.”

The team aims to validate the benefits of mechanotherapy in larger animals and eventually people.

—by Erin Bryant

Related Links

References: Skeletal muscle regeneration with robotic actuation-mediated clearance of neutrophils. Seo BR, Payne CJ, McNamara SL, Freedman BR, Kwee BJ, Nam S, de Lázaro I, Darnell M, Alvarez JT, Dellacherie MO, Vandenburgh HH, Walsh CJ, Mooney DJ. Sci Transl Med. 2021 Oct 6;13(614):eabe8868. doi: 10.1126/scitranslmed.abe8868. Epub 2021 Oct 6. PMID: 34613813.

Funding: NIH’s National Institute of Arthritis and Musculoskeletal and Skin Diseases (NIAMS), National Institute of Dental and Craniofacial Research (NIDCR), Eunice Kennedy Shriver National Institute of Child Health and Human Development (NICHD), National Institute on Aging (NIA), and National Cancer Institute (NCI); National Science Foundation (NSF).
